Features
- Highly integrated: The device is integrated with camera, LCD, LED supplement light, lens, pickup, and speaker, which helps to reduce construction and wiring costs. The all-in-one structure brings simple wiring and convenient debugging.
- High definition: 4 MP HD camera with max. 2688 × 1520 resolution and 25 fps frame rate. High quality imaging with 1/3" progressive scan CMOS. 0.022 lux low illumination with clearer imaging at night.
- LCD: 15.6 inch LCD can also play image, video, and advertisement.
- Supplement light: Embedded with 9 bright LED lights, the device has smart supplement light technology, which supports supplement light control according to time and brightness.
- Remote debugging: 3.1 to 6 mm motor-driven varifocal lens, remote debugging is quick and easy.
- Anti-vehicle following mode: Supports anti-vehicle following mode via video and radar/loop. The boom pole can keep rising in vehicle queue scenario to solve the congestion.
- Ingress protection: The surface of the host adopts anti-UV and electrostatic spraying, and the level of dustproof and waterproof meets the requirement of IP45 for outdoor devices.
- Emergency function: Support emergency power fail boom pole lifting (optional)
Technical specifications
| Screen Dimensions | 15.6 inch |
|---|---|
| Resolution | 1080p |
| Panel Brightness | 1500 cd/m² (MAX) |
| Lens Type | 3.1 to 6 mm varifocal lens, motor-driven lens |
| Matched Boom Pole Type | DS-TMC403-EML/R and /DS-TMC403-EMR/R: DS-TMG001-3D(3m octagonal), DS-TMG001-3D(4m octagonal), DS-TMG001-3D(2.6-4m), DS-TMG002-3D(1.5+1.5m), DS-TMG001-6L(3m reinf)DS-TMC403-ELL/R and /DS-TMC403-ELR/R: DS-TMG001-3D(3.6-6m), DS-TMG002-3D(2+2m), DS-TMG002-3D(2.5+2.5m), DS-TMG001-6L(4m teinf) |
| Rising Speed | 3m: 3s, 4m: 3.5s, 2.6-4m telescopic: 4s, 1.5+1.5 m folding: 3s, 3.6-6 m telescopic: 6.5s, 2+2 m folding: 4s, 2.5+2.5 m folding: 5.5s, 3m light: 3s, 4m light: 3.5s |
| Falling Speed | 3m: 3s, 4m: 3.5s, 2.6-4m telescopic: 4.5s, 1.5+1.5 m folding: 4s, 3.6-6 m telescopic: 7.5s, 2+2 m folding: 6s, 2.5+2.5 m folding: 7s, 3m light: 3s, 4m light: 3.5s |
| Boom Pole Direction | DS-TMC403-EML/R and DS-TMC403-ELL/R: leftDS-TMC403-EMR/R and DS-TMC403-ELR/R: right |
| Boom Pole Falling Delay | 1~600s |
| Motor Type | DC Brushless Motor |
| Number of Cycles | 2500000 |
| Working Voltage | 24VDC |
| Remote Controller Frequency | 433.5 MHz |
| Max. Number of Remote Controller Binding | 64 |
| Temperature and Humidity | Temperature: -30 °C to 70 °C (-22 °F to 158 °F) |
| Rising Boom Pole for Poweroff | Optional, order supercapacitor board independently |
| LED Light Bead | 9 |
| Band/Color Temperature | 3000 K |
| Image Format | JPEG with configurable quality |
| Capture Resolution | 2688 × 1520 |
| Smart Recognition | ANPR, vehicle type recognition, vehicle logo recognition, sub-brand recognition |
| Image Settings | Saturation, brightness, contrast, white balance, AGC, and 3D noise reduction can be adjusted via the web browser. |
| Frame Rate | 25 fps @ (2688 × 1520) |
| Video Compression | H.264/H.265/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Protocol | TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP picture upload |
| Security | Heartbeat, password protection, NTP |
| Max. Resolution | 2688 × 1520 |
| Sensor Type | 1/3" Progressive Scan CMOS |
| Min. Illumination | Color: 0.022 Lux @ (F2.0, AGC ON)B/W: 0.011 Lux @ (F2.0, AGC ON) |
| Shutter | 1/30 s to 1/100,000 s |
| Day/Night Switch | Supported |
| IR Cut Filter | Supported |
| Alarm Input | 2-ch triggered/alarm inputs |
| Alarm Output | 2-ch relay outputs, supporting rising of barrier gate boom pole |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet interface |
| Serial Port | 1 built-in RS-232 serial port |
| Supplement Light Control | Control according to brightness or time |
| Lightning Protection | Supported |
| Working Temperature and Humidity | -30 °C to 70 °C (-22 °F to 158 °F); 90% or less (non-condensing) |
| Power Supply | 100~240 VAC |
| Power Consumption | 200W |
| Dimensions | 1380 × 447 × 303 mm (54.3 × 17.6 × 11.9 inch) |
| Weight (with Package) | 62.56 kg (137.92 lb.) |
| Dimensions (with Package) | 1504 × 573 × 415 mm (59.2 × 22.6 × 16.3 inch) |
| Matched Boom Pole Type | DS-TMC403-EML/R and /DS-TMC403-EMR/R: DS-TMG001-3D(3m octagonal), DS-TMG001-3D(4m octagonal), DS-TMG001-3D(2.6-4m), DS-TMG002-3D(1.5+1.5m), DS-TMG001-6L(3m reinf) DS-TMC403-ELL/R and /DS-TMC403-ELR/R: DS-TMG001-3D(3.6-6m), DS-TMG002-3D(2+2m), DS-TMG002-3D(2.5+2.5m), DS-TMG001-6L(4m teinf) |
| Boom Pole Direction | DS-TMC403-EML/R and DS-TMC403-ELL/R: left DS-TMC403-EMR/R and DS-TMC403-ELR/R: right |
| Min. Illumination | Color: 0.022 Lux @ (F2.0, AGC ON) B/W: 0.011 Lux @ (F2.0, AGC ON) |
