Features
- New fusion smart camera, which can sense the temperature for alarm and can be rechecked via video
- 400W Fixed Focus Intelligent Camera
- Equipped with high-brightness four-color indicator lights to display the running, fault and alarm status
- Supports flame detection, coverage: 30 meters (burning object: n-heptane, 0.1㎡ fire plate)
- Supports high-temperature and temperature-rise exception detection
- Supports local alarm indicator light, high-decibel alarm through an internal speaker, and remote muting
- 1 internal speaker, 1 internal microphone, supports bidirectional voice intercom
- OSD alarm event overlay support
- Supports access to Hik-Protect or Hik-Connect APP
- Supports IR fill light，with maximum range up to 30 meters
- Supports DC 12~24V (±15%) or PoE power supply, with simple wiring
- Supports 1 channel of alarm input and 3 channels of alarm output
- IP67 dust and water resistant
Technical specifications
| Sensor Type | 1/2.9" Progressive Scan CMOS |
|---|---|
| Main Stream | 30 fps (2560*1440，1920 × 1080, 1280 × 720) |
| Max. Resolution | 2560*1440 |
| Sub Stream | 30 fps (704 × 576, 640 × 480，352 × 288)30 |
| Min. Illumination | Color : 0.01 Lux @（F1.6，AGC ON） |
| Lens | Horizontal: 78°, Vertical: 40°, Diagonal: 93° |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC and white balance can be adjusted through the client or browser. |
| WDR | Digital WDR |
| Shutter | 1/25 ~ 1/100,000 s |
| Image Enhancement | Backlight compensation, 3D digital noise reduction, Grayscale range adjustment |
| Main Stream Video Compression Standard | Smart265,Smart264,H.265,H.264 |
| Sub Stream Compression Standard | Smart265,Smart264,H.265,H.264 |
| Video Bitrate | 256Kbps ~ 8192Kbps |
| Intelligent Alarm | Smoke alarm, Fire alarm |
| Protocol | TCP/IP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IPv4, UDP |
| Interface Protocol | ONVIF(PROFILE S, PROFILE G), ISAPI，EZVIZ，ISUP，SDK, GB28181 |
| General | One-click restoration，Anti flicker, Heartbeat,Mirroring，Password protection, Video occlusion，IP address filtering |
| Storage | Micro SD/SDHC/SDXC card (Maximum support 512 GB) |
| Exception Detection | Motion detection, Obstruction alarm, Hard disk full, Hard disk error, Network disconnection, IP address conflict, Illegal access, Peripheral failure |
| WEB Configuration | Support web preview, configuration and parameter import/export |
| IR Range | IR：30m |
| Image Sensor | Vanadium Oxide (VOx) Microbolometer |
| Pixel Size | 120 ×90 |
| Response Waveband | 8~14 μm |
| Focal Length of Thermal Imaging Lens | 1.2 mm |
| Thermal Imaging Field of View | 90° ×68° |
| Palette Mode | Support 15 modes including white hot, black hot, fusion 1, rainbow, fusion 2, iron red 1, iron red 2, etc. |
| Fire and Smoke Detection | Yes |
| Temperature Exception Detection | Yes |
| Temperature Measurement Range | -20 °C~400 °C |
| Thermography Precision | ±8 °C or ±8% of the reading (take the maximum value) (within a distance of 0.3 to 1.5 meters from the device) |
| Noise Equivalent Temperature Difference (NETD) | ≤50 mK(@25 °C,F1.0) |
| Temperature Sensing Mode | Support non-contact temperature sensing |
| High Temperature Alarm | Yes |
| Alarm Interface | 1 way alarm input (Alarm in), 3 ways alarm output (Alarm out) |
| Ethernet Interface | RJ45 10 M/100 M adaptive Ethernet port × 1 |
| Audio Interface | 1 way built-in microphone, 1 way built-in speaker |
| Flame Detection | Yescoverage: 30 meters (burning object: n-heptane, 0.1㎡ fire plate) |
| Smoke Detection | Yes |
| Ingress Protection | IP 67 |
| Mounting Height | Indoor: higher than 2.5 mOutdoor: higher than 3.5 m |
| Power Interface Type | DC 12V round head power interface |
| Power | DC 9V ~ 30V，10W MAX; PoE: 802.3af，CLASS 3 (The power adapter is not included; you will need to configure it yourself) |
| Working Temperature | -20~60°C |
| Working Humidity | ＜95% RH |
| Dimension (φ × H) | 245.7 mm × 80 mm ×80 mm |
| Alarm Indicator Light | Red: AlarmGreen: Operation indicator lightYellow: FaultBlue: Communication status indicator light |
| Product Implementation Standard | Q/HKD 054-2024 |
| Power Consumption | Max 10 W |
| Installation | Support for hanging and wall mounting |
| Flame Detection | Yes coverage: 30 meters (burning object: n-heptane, 0.1㎡ fire plate) |
| Mounting Height | Indoor: higher than 2.5 m Outdoor: higher than 3.5 m |
| Alarm Indicator Light | Red: Alarm Green: Operation indicator light Yellow: Fault Blue: Communication status indicator light |
